Samsara supports the use of third-party Pelco cameras with your Connected Sites deployment.
Samsara supports the following Pelco camera models:
| Model | Description | Resources | |||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SRXV2-5V13-EMD-IR | Sarix Value 2 Outdoor Dome Camera[a][a] | ||||||||||||||||||||||||||||||||||||||||||||||||
| SRXV2-5V13-EBT-IR | Sarix Value 2 Bullet Camera | ||||||||||||||||||||||||||||||||||||||||||||||||
| SRXV2-2F3-EWD-IR | Sarix Value 2 Wedge Camera | ||||||||||||||||||||||||||||||||||||||||||||||||
| SRXP4-2V10-EMD-IR | Sarix Pro 4 Series Dome Camera (Smart Dome) [b][b] | ||||||||||||||||||||||||||||||||||||||||||||||||
| SRXP4-8V9-EBT-IR | Sarix Pro 4 Series Bullet Camera (Smart Bullet) [b] | ||||||||||||||||||||||||||||||||||||||||||||||||
| IMF82-1ES | Smart Fisheye Camera [b] | Smart Fisheye Camera Spec Sheet | |||||||||||||||||||||||||||||||||||||||||||||||
|
[a] Available in 2MP White light version [b] Pelco camera analytics are not visible in Samsara | |||||||||||||||||||||||||||||||||||||||||||||||||
Similar to other third-party cameras, Pelco cameras are not configured through the Samsara dashboard. To connect the camera to Samsara:
-
Install the camera and any additional audio equipment per the manufacturer's instructions.
The Value Dome and Turret Cameras include a built-in microphone. Other Pelco camera models may also support audio recording through the installation of an external microphone. Refer to the manufacturer's specifications.
-
Set an initial username and password for the camera.
Use one of the following methods:
- Pelco Camera Configuration Tool
- By web browser, navigate to the IP address of the camera.
Tip
You can obtain the IP address of the camera using Pelco Camera Configuration Tool.
If DHCP is enabled but a DHCP server is not on the network, the camera will use a standard Zeroconf algorithm to set the IP address in the 169.254.1.0 to 169.254.254.255 range. To find the camera, you can set up a NIC with an address of 169.254.0.1 and a netmask of 255.255.0.0. Then use any WS Discovery tool to find the camera.
The camera also comes preconfigured with a username of
rootand no password.Note
If you do not set the credentials, you will get an error when you attempt to authenticate the camera from the Samsara dashboard.
- Proceed to Manually Add a Third-Party IP Camera.
You can use the Camera Configuration Tool to set initial credentials on your cameras and set other configurations. The tool requires a Windows computer.
For more information, see the following Pelco resources:
- Pelco Camera Configuration Tool Overview
- Pelco Camera Configuration Tool User Guide – For steps about setting initial credentials, review the Changing the Factory Default Credentials section of the user guide.
